:SBUS<n> Commands 31
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1081
:SBUS<n>:SPI:SOURce:FRAMe
(see page 1610)
Command Syntax
:SBUS<n>:SPI:SOURce:FRAMe <source>
<source> ::= {CHANnel<n> | EXTernal} for the DSO models
<source> ::= {CHANnel<n> | DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels) in NR1 format
<d> ::= 0 to (# digital channels - 1) in NR1 format
The :SBUS<n>:SPI:SOURce:FRAMe command sets the frame source when
:SBUS<n>:SPI:FRAMing is set to CHIPselect or NOTChipselect.
Query Syntax
:SBUS<n>:SPI:SOURce:FRAMe?
The :SBUS<n>:SPI:SOURce:FRAMe? query returns the current frame source for the
SPI serial frame.
Return Format
<source><NL>
See Also • "Introduction to :TRIGger Commands" on page 1295
• ":SBUS<n>:SPI:SOURce:CLOCk" on page 1080
• ":SBUS<n>:SPI:SOURce:MOSI" on page 1083
• ":SBUS<n>:SPI:SOURce:MISO" on page 1082
• ":SBUS<n>:SPI:FRAMing" on page 1079
