29 :SBUS<n> Commands
:SBUS<n>:A429:TRIGger:PATTern:DATA
(see page 1428)
Command Syntax
:SBUS<n>:A429:TRIGger:PATTern:DATA <string>
<string> ::= "nn...n" where n ::= {0 |1|X},length depends on FORMat
The :SBUS<n>:A429:TRIGger:PATTern:DATA command defines the ARINC 429
data pattern resource according to the string parameter. This pattern controls the
data pattern searched for in each ARINC 429 word.
Query Syntax
:SBUS<n>:A429:TRIGger:PATTern:DATA?
The :SBUS<n>:A429:TRIGger:PATTern:DATA? query returns the current settings of
the specified ARINC 429 data pattern resource in the binary string format.
Return Format
<string><NL> in nondecimal format
Errors • "-241, Hardware missing" on page 1387
See Also • "Introduction to :TRIGger Commands" on page 1139
• ":SBUS<n>:A429:TRIGger:TYPE" on page 776
• ":SBUS<n>:A429:TRIGger:PATTern:SDI" on page 773
• ":SBUS<n>:A429:TRIGger:PATTern:SSM" on page 774
NOTE
If more bits are sent for <string> than specified by the :SBUS<n>:A429:FORMat command, the
most significant bits will be truncated.
