1216 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
33 :TRIGger Commands
:TRIGger:TV:LINE
(see page 1428)
Command Syntax
:TRIGger:TV:LINE <line_number>
<line_number> ::= integer in NR1 format
The :TRIGger:TV:LINE command allows triggering on a specific line of video. The
line number limits vary with the standard and mode, as shown in the following
table.
Query Syntax
:TRIGger:TV:LINE?
The :TRIGger:TV:LINE? query returns the current TV trigger line number setting.
Return Format
<line_number><NL>
<line_number>::= integer in NR1 format
See Also • "Introduction to :TRIGger Commands" on page 1139
• ":TRIGger:TV:STANdard" on page 1220
• ":TRIGger:TV:MODE" on page 1217
Table 156 TV Trigger Line Number Limits
TV Standard Mode
LINE LFIeld1 LFIeld2 LALTernate VERTical
NTSC 1 to 263 1 to 262 1 to 262
PAL 1 to 313 314 to 625 1 to 312
PAL-M 1 to 263 264 to 525 1 to 262
SECAM 1 to 313 314 to 625 1 to 312
GENERIC 1 to 1024 1 to 1024 1 to 1024
P480L60HZ 1 to 525
P720L60HZ 1 to 750
P1080L24HZ 1 to 1125
P1080L25HZ 1 to 1125
P1080L50HZ 1 to 1125
P1080L60HZ 1 to 1125
I1080L50HZ 1 to 1125
I1080L60HZ 1 to 1125
