:TRIGger:TV Commands
Table 155 :TRIGger:TV Commands Summary
Command Query Options and Query Returns
:TRIGger:TV:LINE
<line number> (see
page 1216)
:TRIGger:TV:LINE?
(see page 1216)
<line number> ::= integer in NR1
format
:TRIGger:TV:MODE <tv
mode> (see page 1217)
:TRIGger:TV:MODE?
(see page 1217)
<tv mode> ::= {FIEld1 | FIEld2 |
AFIelds | ALINes | LINE | LFIeld1
| LFIeld2 | LALTernate}
:TRIGger:TV:POLarity
<polarity> (see
page 1218)
:TRIGger:TV:POLarity?
(see page 1218)
<polarity> ::= {POSitive |
NEGative}
:TRIGger:TV:SOURce
<source> (see
page 1219)
:TRIGger:TV:SOURce?
(see page 1219)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger:TV:STANdard
<standard> (see
page 1220)
:TRIGger:TV:STANdard?
(see page 1220)
<standard> ::= {NTSC | PAL | PALM
| SECam}
<standard> ::= {GENeric |
{P480L60HZ | P480} | {P720L60HZ |
P720} | {P1080L24HZ | P1080} |
P1080L25HZ | P1080L50HZ |
P1080L60HZ | {I1080L50HZ | I1080}
| I1080L60HZ} with extended video
triggering license
:TRIGger:TV:UDTV:ENUM
ber <count> (see
page 1221)
:TRIGger:TV:UDTV:ENUM
ber? (see page 1221)
<count> ::= edge number in NR1
format
:TRIGger:TV:UDTV:HSYN
c {{0 | OFF} | {1 |
ON}} (see page 1222)
:TRIGger:TV:UDTV:HSYN
c? (see page 1222)
{0 | 1}
:TRIGger:TV:UDTV:HTIM
e <time> (see
page 1223)
:TRIGger:TV:UDTV:HTIM
e? (see page 1223)
<time> ::= seconds in NR3 format
:TRIGger:TV:UDTV:PGTH
an <min_time> (see
page 1224)
:TRIGger:TV:UDTV:PGTH
an? (see page 1224)
<min_time> ::= seconds in NR3
format
