35 :WGEN<w> Commands
:WGEN<w>:TRACk
(see page 1428)
Command Syntax
:WGEN<w>:TRACk <on_off>
<w> ::= 1 or 2 in NR1 format
<on_off> ::= {{1 | ON} | {0 | OFF}
The :WGEN<w>:TRACk ON command causes frequency, amplitude, offset, and
duty cycle adjustments to this waveform generator output signal to be tracked by
the other waveform generator output.
Not all waveform shapes can be frequency tracked. When :WGEN<w>:TRACk or
:WGEN<w>:TRACk:FREQuency is enabled, the other generator's waveform
selections (:WGEN<w>:FUNCtion) must be in the same group as this generator's
waveform:
When tracking is enabled, adjustments for tracked settings in the other waveform
generator become unavailable.
Query Syntax
:WGEN<w>:TRACk?
The :WGEN<w>:TRACk? query returns whether tracking is on or off.
Return Format
<on_off><NL>
<on_off> ::= {1 | 0}
See Also • ":WGEN<w>:FUNCtion" on page 1282
• ":WGEN<w>:TRACk:AMPLitude" on page 1309
• ":WGEN<w>:TRACk:FREQuency" on page 1311
• ":WGEN<w>:TRACk:PHASe" on page 1312
• ":WGEN<w>:TRACk:CSIGnal" on page 1310
Group 1 Group 2 Group 3 Group 4
SINusoid
RAMP
SINC
CARDiac
GAUSsian
SQUare
PULSe
EXPRise
EXPFall
ARBitrary
