:CALibrate Commands 9
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 293
:CALibrate:OUTPut
(see page 1428)
Command Syntax
:CALibrate:OUTPut <signal>
<signal> ::= {TRIGgers | MASK | WAVEgen | WGEN1 | WGEN2 | NFC}
Note: WAVE and WGEN1 are equivalent.
Note: WGEN2 only available on models with 2 WaveGen outputs.
The CALibrate:OUTPut command sets the signal that is available on the rear panel
TRIG OUT BNC:
• TRIGgers — pulse when a trigger event occurs.
• MASK — signal from mask test indicating a failure.
• WAVEgen, WGEN1, WGEN2 — waveform generator sync output signal. This
signal depends on the :WGEN<w>:FUNCtion setting:
• NFC — This option is available in the Near Field Communication (NFC) trigger
mode when the ATRigger (Arm & Trigger) trigger event is selected (see
":TRIGger:NFC:TEVent" on page 1184). The ATRigger trigger event lets you arm
the oscilloscope on one event and then trigger on a second event or after a
specified timeout period if the second event does not occur.
When :CALibrate:OUTPut is NFC and the specified event arms, the TRIG
OUTBNC goes high. The oscilloscope waits until a second event is found or
until the specified timeout period expires and then triggers.
• For NFC-A, the second event is SDD_REQ.
• For NFC-B, the second event is ATTRIB.
• For NFC-F, the second event is ATR_REQ.
When the oscilloscope triggers, the TRIG OUTBNC line goes low.
Query Syntax
:CALibrate:OUTPut?
Waveform
Type
Sync Signal Characteristics
SINusoid,
SQUare,
RAMP, PULSe,
SINC,
EXPRise,
EXPFall,
GAUSsian
The Sync signal is a TTL positive pulse that occurs when the waveform rises above
zero volts (or the DC offset value).
DC, NOISe,
CARDiac
N/A
