29 :SBUS<n> Commands
:SBUS<n>:USB Commands
NOTE
These commands are only valid when a USB 2.0 triggering and serial decode option
(Option USF or Option U2H) has been licensed.
Table 124 :SBUS<n>:USB Commands Summary
Command Query Options and Query Returns
:SBUS<n>:USB:BASE
<base> (see page 971)
:SBUS<n>:USB:BASE?
(see page 971)
<base> ::= {ASCii | BINary |
DECimal | HEX}
:SBUS<n>:USB:SOURce:D
MINus <source> (see
page 972)
:SBUS<n>:USB:SOURce:D
MINus? (see page 972)
<source> ::= {CHANnel<n>} for DSO
models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:USB:SOURce:D
PLus <source> (see
page 973)
:SBUS<n>:USB:SOURce:D
PLus? (see page 973)
<source> ::= {CHANnel<n>} for DSO
models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:USB:SOURce:D
IFFerential <source>
(see page 974)
:SBUS<n>:USB:SOURce:D
IFFerential? (see
page 974)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:USB:SPEed
<speed> (see page 975)
:SBUS<n>:USB:SPEed?
(see page 975)
<speed> ::= {LOW | FULL | HIGH}
:SBUS<n>:USB:TRIGger
<condition> (see
page 976)
:SBUS<n>:USB:TRIGger?
(see page 976)
<condition> ::= {SOP | EOP |
ENTersuspend | EXITsuspend |
RESet | TOKen | DATA | HANDshake
| SPECial | ALLerrors | PIDerror
| CRC5error | CRC16error |
GLITcherror | STUFFerror |
SE1error}
:SBUS<n>:USB:TRIGger:
ADDRess <string> (see
page 977)
:SBUS<n>:USB:TRIGger:
ADDRess? (see
page 977)
<string> ::= "nnnnnnn" where n
::= {0 | 1 | X}
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F | X | $}
