Keysight InfiniiVision 4000 X-Series Oscilloscopes
Programmer's Guide
17 :EXTernal Trigger Commands
Control the input characteristics of the external trigger input. See "Introduction to
:EXTernal Trigger Commands" on page 383.
Introduction to
:EXTernal Trigger
Commands
The EXTernal trigger subsystem commands control the input characteristics of the
external trigger input. The probe factor, impedance, input range, input protection
state, units, and bandwidth limit settings may all be queried. Depending on the
instrument type, some settings may be changeable.
Reporting the Setup
Use :EXTernal? to query setup information for the EXTernal subsystem.
Return Format
The following is a sample response from the :EXTernal query. In this case, the
query was issued following a *RST command.
:EXT:BWL 0;RANG +8.0E+00;UNIT VOLT;PROB +1.000E+00
Table 100 :EXTernal Trigger Commands Summary
Command Query Options and Query Returns
:EXTernal:BWLimit
<bwlimit> (see
page 384)
:EXTernal:BWLimit?
(see page 384)
<bwlimit> ::= {0 | OFF}
:EXTernal:PROBe
<attenuation> (see
page 385)
:EXTernal:PROBe? (see
page 385)
<attenuation> ::= probe
attenuation ratio in NR3 format
:EXTernal:RANGe
<range>[<suffix>]
(see page 386)
:EXTernal:RANGe? (see
page 386)
<range> ::= vertical full-scale
range value in NR3 format
<suffix> ::= {V | mV}
:EXTernal:UNITs
<units> (see page 387)
:EXTernal:UNITs? (see
page 387)
<units> ::= {VOLT | AMPere}
