1340 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide

35 :TRIGger Commands

:TRIGger:NFC:AEVent

(see page 1610)

Command Syntax

:TRIGger:NFC:AEVent <arm_event>

<arm_event> ::= {NONE | ASReq | AALLreq | AEITher | BSReq | BALLreq

| BEITher | FSReq}

When the ATRigger (Arm & Trigger) trigger event is selected (by

:TRIGger:NFC:TEVent), the :TRIGger:NFC:AEVent command specifies the arm

event. Valid arm event settings depend on the signaling technology selected (by

:TRIGger:NFC:STANdard):

When a trigger event other than ATRigger (Arm & Trigger) is selected, the arm

event is NONE.

Query Syntax

:TRIGger:NFC:AEVent?

The :TRIGger:NFC:AEVent? query returns the specified arm event.

Return Format

<arm_event><NL>

<arm_event> ::= {NONE | ASR | AALL | AEIT | BSR | BALL | BEIT | FSR}

See Also • ":TRIGger:NFC:ATTime" on page 1341

• ":TRIGger:NFC:RPOLarity" on page 1342

• ":TRIGger:NFC:SOURce" on page 1343

• ":TRIGger:NFC:STANdard" on page 1344

• ":TRIGger:NFC:TEVent" on page 1345

• ":TRIGger:NFC:TIMeout" on page 1347

• ":TRIGger:NFC:TIMeout:ENABle" on page 1348

• ":TRIGger:NFC:TIMeout:TIME" on page 1349

Signaling

Technology

Arm Event Description

NFC-A ASReq SENS_REQ

AALLreq ALL_REQ

AEITher Either the SENS_REQ or ALL_REQ events will arm.

NFC-B BSReq SENSB_REQ

BALLreq ALLB_REQ

BEITher Either the SENSB_REQ or ALLB_REQ events will arm.

NFC-F FSReq SENSF_REQ
