Keysight Technologies InfiniiVision MSO-X 4154A

104 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:FUNCtion<m>[:FFT]:WI
NDow <window> (see
page 409)
:FUNCtion<m>[:FFT]:WI
NDow? (see page 409)
<window> ::= {RECTangular |
HANNing | FLATtop | BHARris}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:FREQuenc
y:HIGHpass <3dB_freq>
(see page 410)
:FUNCtion<m>:FREQuenc
y:HIGHpass? (see
page 410)
<3dB_freq> ::= 3dB cutoff
frequency value in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:FREQuenc
y:LOWPass <3dB_freq>
(see page 411)
:FUNCtion<m>:FREQuenc
y:LOWPass? (see
page 411)
<3dB_freq> ::= 3dB cutoff
frequency value in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:INTegrat
e:IOFFset
<input_offset> (see
page 412)
:FUNCtion<m>:INTegrat
e:IOFFset? (see
page 412)
<input_offset> ::= DC offset
correction in NR3 format.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:LINear:G
AIN <value> (see
page 413)
:FUNCtion<m>:LINear:G
AIN? (see page 413)
<value> ::= 'A' in Ax + B, value
in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:LINear:O
FFSet <value> (see
page 414)
:FUNCtion<m>:LINear:O
FFSet? (see page 414)
<value> ::= 'B' in Ax + B, value
in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:OFFSet
<offset> (see
page 415)
:FUNCtion<m>:OFFSet?
(see page 415)
<offset> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:OPERatio
n <operation> (see
page 416)
:FUNCtion<m>:OPERatio
n? (see page 418)
<operation> ::= {ADD | SUBTract |
MULTiply | DIVide | INTegrate |
DIFF | FFT | FFTPhase | SQRT |
MAGNify | ABSolute | SQUare | LN
| LOG | EXP | TEN | LOWPass |
HIGHpass | AVERage | LINear |
MAXimum | MINimum | PEAK |
MAXHold | MINHold | TRENd |
BTIMing | BSTate}
<m> ::= 1 to (# math functions)
in NR1 format
Table 15 :FUNCtion<m> Commands Summary (continued)
Command Query Options and Query Returns
