Keysight Technologies InfiniiVision MSO-X 4154A

1524 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
42 Programming Examples
SICL Examples
• "SICL Example in C" on page 1524
• "SICL Example in Visual Basic" on page 1533
SICL Example in C
To compile and run this example in Microsoft Visual Studio 2008:
1 Open Visual Studio.
2 Create a new Visual C++, Win32, Win32 Console Application project.
3 In the Win32 Application Wizard, click Next >. Then, check Empty project, and
click Finish.
4 Cut-and-paste the code that follows into a file named "example.c" in the
project directory.
5 In Visual Studio 2008, right-click the Source Files folder, choose Add > Add
Existing Item..., select the example.c file, and click Add.
6 Edit the program to use the SICL address of your oscilloscope.
7 Choose Project > Properties.... In the Property Pages dialog, update these project
settings:
a Under Configuration Properties, Linker, Input, add "sicl32.lib" to the
Additional Dependencies field.
b Under Configuration Properties, C/C++, Code Generation, select
Multi-threaded DLL for the Runtime Library field.
c Click OK to close the Property Pages dialog.
8 Add the include files and library files search paths:
a Choose Tools > Options....
b In the Options dialog, select VC++ Directories under Projects and Solutions.
c Show directories for Include files, and add the include directory (for example,
Program Files\Keysight\IO Libraries Suite\include).
d Show directories for Library files, and add the library files directory (for
example, Program Files\Keysight\IO Libraries Suite\lib).
e Click OK to close the Options dialog.
9 Build and run the program.
/*
* Keysight SICL Example in C
* ------------------------------------------------------------------
* This program illustrates a few commonly-used programming
* features of your Keysight oscilloscope.
*/
#include <stdio.h> /* For printf(). */
