4 Commands Quick Reference
Table 18 :MARKer Commands Summary
Command Query Options and Query Returns
n/a :MARKer:DYDX? (see
page 454)
<return_value> ::= •Y/•X value in
NR3 format
:MARKer:MODE <mode>
(see page 455)
:MARKer:MODE? (see
page 455)
<mode> ::= {OFF | MEASurement |
MANual | WAVeform | BINary | HEX}
:MARKer:X1:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 456)
:MARKer:X1:DISPlay?
(see page 456)
<setting> ::= {0 | 1}
:MARKer:X1Position
<position>[suffix]
(see page 457)
:MARKer:X1Position?
(see page 457)
<position> ::= X1 cursor position
value in NR3 format
[suffix] ::= {s | ms | us | ns |
ps | Hz | kHz | MHz}
<return_value> ::= X1 cursor
position value in NR3 format
:MARKer:X1Y1source
<source> (see
page 458)
:MARKer:X1Y1source?
(see page 458)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= <source>
:MARKer:X2:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 459)
:MARKer:X2:DISPlay?
(see page 459)
<setting> ::= {0 | 1}
:MARKer:X2Position
<position>[suffix]
(see page 460)
:MARKer:X2Position?
(see page 460)
<position> ::= X2 cursor position
value in NR3 format
[suffix] ::= {s | ms | us | ns |
ps | Hz | kHz | MHz}
<return_value> ::= X2 cursor
position value in NR3 format
:MARKer:X2Y2source
<source> (see
page 461)
:MARKer:X2Y2source?
(see page 461)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= <source>
