29 :SBUS<n> Commands
:SBUS<n>:CAN:TRIGger:SYMBolic:VALue
(see page 1428)
Command Syntax
:SBUS<n>:CAN:TRIGger:SYMBolic:VALue <data>
<data> ::= value in NR3 format
The :SBUS<n>:CAN:TRIGger:SYMBolic:VALue command specifies the signal value
to trigger on when CAN symbolic data has been loaded (recalled) into the
oscilloscope and the CAN trigger mode is set to MSIGnal.
Query Syntax
:SBUS<n>:CAN:TRIGger:SYMBolic:VALue?
The :SBUS<n>:CAN:TRIGger:SYMBolic:VALue? query returns the specified signal
value.
Return Format
<data><NL>
<data> ::= value in NR3 format
See Also • ":RECall:DBC[:STARt]" on page 716
• ":SBUS<n>:CAN:TRIGger" on page 794
• ":SBUS<n>:CAN:TRIGger:SYMBolic:MESSage" on page 804
• ":SBUS<n>:CAN:TRIGger:SYMBolic:SIGNal" on page 805
NOTE
Encoded signal values are not supported in the remote interface (even though they can be
used in the front panel graphical interface).
