1126 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
32 :TIMebase Commands
Introduction to
:TIMebase
Commands
The TIMebase subsystem commands control the horizontal (X-axis) functions and
set the oscilloscope to X-Y mode (where channel 1 becomes the X input and
channel 2 becomes the Y input). The time per division, delay, vernier control, and
reference can be controlled for the main and window (zoomed) time bases.
Reporting the Setup
Use :TIMebase? to query setup information for the TIMebase subsystem.
Return Format
The following is a sample response from the :TIMebase? query. In this case, the
query was issued following a *RST command.
:TIM:MODE MAIN;REF CENT;MAIN:RANG +1.00E-03;POS +0.0E+00
:TIMebase:WINDow:RANG
e <range_value> (see
page 1136)
:TIMebase:WINDow:RANG
e? (see page 1136)
<range value> ::= range value in
seconds in NR3 format for the
zoomed window
:TIMebase:WINDow:SCAL
e <scale_value> (see
page 1137)
:TIMebase:WINDow:SCAL
e? (see page 1137)
<scale_value> ::= scale value in
seconds in NR3 format for the
zoomed window
Table 143 :TIMebase Commands Summary (continued)
Command Query Options and Query Returns
