Keysight InfiniiVision 4000 X-Series Oscilloscopes
Programmer's Guide
32 :TIMebase Commands
Control all horizontal sweep functions. See "Introduction to :TIMebase
Commands" on page 1126.
Table 143 :TIMebase Commands Summary
Command Query Options and Query Returns
:TIMebase:MODE
<value> (see
page 1127)
:TIMebase:MODE? (see
page 1127)
<value> ::= {MAIN | WINDow | XY |
ROLL}
:TIMebase:POSition
<pos> (see page 1128)
:TIMebase:POSition?
(see page 1128)
<pos> ::= time from the trigger
event to the display reference
point in NR3 format
:TIMebase:RANGe
<range_value> (see
page 1129)
:TIMebase:RANGe? (see
page 1129)
<range_value> ::= time for 10 div
in seconds in NR3 format
:TIMebase:REFClock
{{0 | OFF} | {1 |
ON}} (see page 1130)
:TIMebase:REFClock?
(see page 1130)
{0 | 1}
:TIMebase:REFerence
{LEFT | CENTer |
RIGHt | CUSTom} (see
page 1131)
:TIMebase:REFerence?
(see page 1131)
<return_value> ::= {LEFT | CENTer
| RIGHt | CUSTom}
:TIMebase:REFerence:L
OCation <loc> (see
page 1132)
:TIMebase:REFerence:L
OCation? (see
page 1132)
<loc> ::= 0.0 to 1.0 in NR3
format
:TIMebase:SCALe
<scale_value> (see
page 1133)
:TIMebase:SCALe? (see
page 1133)
<scale_value> ::= time/div in
seconds in NR3 format
:TIMebase:VERNier {{0
| OFF} | {1 | ON}}
(see page 1134)
:TIMebase:VERNier?
(see page 1134)
{0 | 1}
:TIMebase:WINDow:POSi
tion <pos> (see
page 1135)
:TIMebase:WINDow:POSi
tion? (see page 1135)
<pos> ::= time from the trigger
event to the zoomed view
reference point in NR3 format
