RAMP Use these commands to set the ramp signal
parameters:
• ":WGEN<w>:FREQuency" on page 1281
• ":WGEN<w>:PERiod" on page 1306
• ":WGEN<w>:VOLTage" on page 1313
• ":WGEN<w>:VOLTage:OFFSet" on
page 1316
• ":WGEN<w>:VOLTage:HIGH" on page 1314
• ":WGEN<w>:VOLTage:LOW" on page 1315
• ":WGEN<w>:FUNCtion:RAMP:SYMMetry"
on page 1287
Symmetry represents the amount of time per cycle
that the ramp waveform is rising and can be
adjusted from 0% to 100%.
100 mHz to
200 kHz
20 mVpp to
10 Vpp
±5.00 V
PULSe Use these commands to set the pulse signal
parameters:
• ":WGEN<w>:FREQuency" on page 1281
• ":WGEN<w>:PERiod" on page 1306
• ":WGEN<w>:VOLTage" on page 1313
• ":WGEN<w>:VOLTage:OFFSet" on
page 1316
• ":WGEN<w>:VOLTage:HIGH" on page 1314
• ":WGEN<w>:VOLTage:LOW" on page 1315
• ":WGEN<w>:FUNCtion:PULSe:WIDTh" on
page 1286
The pulse width can be adjusted from 20 ns to the
period minus 20 ns.
100 mHz to
10 MHz.
20 mVpp to
10 Vpp
±5.00 V
DC Use this command to set the DC level:
• ":WGEN<w>:VOLTage:OFFSet" on
page 1316
n/a n/a ±10.00 V
NOISe Use these commands to set the noise signal
parameters:
• ":WGEN<w>:VOLTage" on page 1313
• ":WGEN<w>:VOLTage:OFFSet" on
page 1316
• ":WGEN<w>:VOLTage:HIGH" on page 1314
• ":WGEN<w>:VOLTage:LOW" on page 1315
n/a 20 mVpp to
10 Vpp
±5.00 V
Waveform
Type
Characteristics Frequency
Range
Max.
Amplitude
2
(High-Z)
1
Offset
2
(High-Z)
1
