122 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:MEASure:VMIN
[<source>] (see
page 545)
:MEASure:VMIN?
[<source>] (see
page 545)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= minimum
voltage of the selected waveform
in NR3 format
:MEASure:VPP
[<source>] (see
page 546)
:MEASure:VPP?
[<source>] (see
page 546)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= voltage
peak-to-peak of the selected
waveform in NR3 format
:MEASure:VRATio
[<interval>][,<source
1>] [,<source2>] (see
page 547)
:MEASure:VRATio?
[<interval>][,<source
1>] [,<source2>] (see
page 547)
<interval> ::= {CYCLe | DISPlay}
<source1,2> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= the ratio
value in dB in NR3 format
Table 19 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
