29 :SBUS<n> Commands
• SAMPleerror — triggers when 10 consecutive logical 0s are detected.
• ALLerrors — triggers on all CRC, Parity, IBS, Stop Bit, Data Length, and Sample
errors.
• SLEepframe — triggers when a normal frame is transmitted matching the
definition of a sleep frame in the CXPI specification.
• WAKeuppulse — triggers when a wakeup pulse is detected.
Query Syntax
:SBUS<n>:CXPI:TRIGger?
The :SBUS<n>:CXPI:TRIGger? query returns the CXPI trigger type setting.
Return Format
<mode><NL>
<mode> ::= {SOF | EOF | PTYP | ID | DATA | LDAT | CRC | PAR | IBS
| IFS | FRAM | DLEN | SAMP | ALL | SLE | WAK}
See Also • ":SBUS<n>:CXPI:BAUDrate" on page 809
• ":SBUS<n>:CXPI:PARity" on page 810
• ":SBUS<n>:CXPI:SOURce" on page 811
• ":SBUS<n>:CXPI:TOLerance" on page 812
• ":SBUS<n>:CXPI:TRIGger:IDFilter" on page 815
• ":SBUS<n>:CXPI:TRIGger:PTYPe" on page 816
• ":SBUS<n>:CXPI:TRIGger:PATTern:DATA" on page 817
• ":SBUS<n>:CXPI:TRIGger:PATTern:DATA:LENGth" on page 818
• ":SBUS<n>:CXPI:TRIGger:PATTern:DATA:STARt" on page 819
• ":SBUS<n>:CXPI:TRIGger:PATTern:ID" on page 820
• ":SBUS<n>:CXPI:TRIGger:PATTern:INFO:CT" on page 821
• ":SBUS<n>:CXPI:TRIGger:PATTern:INFO:DLC" on page 822
• ":SBUS<n>:CXPI:TRIGger:PATTern:INFO:NM" on page 823
