Keysight Technologies InfiniiVision MSO-X 4154A

124 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:MEASure:XMAX
[<source>] (see
page 552)
:MEASure:XMAX?
[<source>] (see
page 552)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
:MEASure:XMIN
[<source>] (see
page 553)
:MEASure:XMIN?
[<source>] (see
page 553)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
Table 19 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
Table 20 :MEASure Power Commands Summary
Command Query Options and Query Returns
:MEASure:ANGLe
[<source1>][,<source2
>] (see page 559)
:MEASure:ANGLe?
[<source1>][,<source2
>] (see page 559)
<source1>, <source2> ::=
{CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= the power
phase angle in degrees in NR3
format
:MEASure:APParent
[<source1>][,<source2
>] (see page 560)
:MEASure:APParent?
[<source1>][,<source2
>] (see page 560)
<source1>, <source2> ::=
{CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= the apparent
power value in NR3 format
