15 :DISPlay Commands
Introduction to
:DISPlay
Commands
The DISPlay subsystem is used to control the display storage and retrieval of
waveform data, labels, and text. This subsystem allows the following actions:
• Clear the waveform area on the display.
• Turn vectors on or off.
• Set waveform persistence.
• Specify labels.
• Save and Recall display data.
Reporting the Setup
Use :DISPlay? to query the setup information for the DISPlay subsystem.
n/a :DISPlay:DATA?
[<format>][,][<palett
e>] (see page 369)
<format> ::= {BMP | BMP8bit |
PNG}
<palette> ::= {COLor | GRAYscale}
<display data> ::= data in IEEE
488.2 # format
:DISPlay:INTensity:WA
Veform <value> (see
page 370)
:DISPlay:INTensity:WA
Veform? (see page 370)
<value> ::= an integer from 0 to
100 in NR1 format.
:DISPlay:LABel {{0 |
OFF} | {1 | ON}} (see
page 371)
:DISPlay:LABel? (see
page 371)
{0 | 1}
:DISPlay:LABList
<binary block> (see
page 372)
:DISPlay:LABList?
(see page 372)
<binary block> ::= an ordered
list of up to 75 labels, each 10
characters maximum, separated by
newline characters
:DISPlay:MENU <menu>
(see page 373)
n/a <menu> ::= {MASK | MEASure |
SEGMented | LISTer | POWer}
:DISPlay:SIDebar
<sidebar> (see
page 374)
n/a <sidebar> ::= {SUMMary | CURSors
| MEASurements | DVM | NAVigate |
CONTrols | EVENts | COUNter}
:DISPlay:PERSistence
<value> (see page 375)
:DISPlay:PERSistence?
(see page 375)
<value> ::= {MINimum | INFinite |
<time>}
<time> ::= seconds in in NR3
format from 100E-3 to 60E0
:DISPlay:VECTors {{0
| OFF} | {1 | ON}}
(see page 376)
:DISPlay:VECTors?
(see page 376)
{0 | 1}
OFF or 0 can only be selected
with the 1 GHz or 1.5 GHz
bandwidth models
Table 98 :DISPlay Commands Summary (continued)
Command Query Options and Query Returns
