Group 8 Job Editor Page 189
JET3up Release R1.06
Figure 85 Stop after x products - pre-defined print stop
Select <Stop after x Products / 1 or 2 product counters
Basically this function works the same way no matter whether there are one or two
product counters defined. A second product counter does not have any effect on
this function. The only difference is the look of the status field.
The dialog box of the <Stop after x Products> function is a submenu of the
<Product counter> menu.
The parameter can either be set with the virtual keyboard or with the arrow keys.
Red frame as <Stop after
x Product setting>
indicator
With one production
counter
Red frame as
<Stop after x Product
setting> indicator
With two production
counters
The settings are
confirmed with the
<Set> button.
Depending on whether there is a second production
counter defined or not the status field looks different.
1 – <Product Counter> Options
6 – Numeric keypad
2 – <Stop after x Products> Option
7 – <Set> Button
3 – Dialog box <Stop at xProducts>
8 – <Cancel> Button
4 – Arrow keys
9 – Sta. field <Prod. Counter> 1 counter
5 – Input field
10 – Sta. field <Prod. Counter> 2 counter
2
1
5
6
8
3
3
5
4
7
8
9
10
