Leibinger JET3 up - Figure 56 Remote Screen - Password; Figure 57 Remote Screen - Indicator Remote Mode; Remote Sreen

Page 146 Job Editor Group 8
Release R1.06 JET3up
7.3.1.10 Remote sreen
The JET3up printer provides a VNC server for remote access. Basically it takes two
steps to use the VNC server of the printer:
1. Assign a password for the VNC server
2. Start the VNC server
This access to the VNC server
is password protected. This password is set on the
tab <Remote screen>.
Figure 56 Remote Screen - Password
1 – Dialog box <Basic Settings>
3 – Input <VNC Password>
2 – Tab <Remote Screen>
A click on the Main window option <Extra> - <Start Remote Screen> will start
the VNC server. The active VNC server is indicated by a status display
in the main
window.
In order to stop the VNC server click on the Main window option <Extra> -
<Close Remote Screen>.
Figure 57 Remote Screen – Indicator remote mode
1 – Main window
3 – Option <Start Remote Screen>
2 – Main window menu item <Extra>
4 – Status display <Remote mode
available>
1
2
3
1
2
3
4
