Leibinger JET3 up - Figure 20 Numeric Keypad Design; Numeric Keypad

Group 8 Job Editor Page 77
JET3up Release R1.06
6.4.1 Numeric keypad
Figure 20 Numeric keypad design
1 – Display
2 –<Backspace> key
3 –<del> key
4 –<> key
5 –<> key
6 –<Return> key
Numbers are entered with the numeric keypad.
The entered value is shown in the Display (1).
The < Backspace
←
> key (2)
deletes the character in front of (to the left of) the
current cursor position.
The <del> key (3)
enables the deletion of the characters behind (to the right of)
the current cursor position.
With the <

> key (4)
you can shift the current cursor position by one digit to the
right.
With the <

> key (5)
you can shift the current cursor position by one digit to the
left.
With the <Return ↵> key (6)
you can take over the input and the Numeric keypad
closes.
2
3
6
1
4
5
