Leibinger JET3 up - Figure 9 Reservoir Tank and Re-Filling Process

Group 5 Transport/Start up Page 53
JET3up Release R1.06
Figure 9 Reservoir tank and re-filling process
Indicating label
Marking of reservoir tanks
Marking of the admissible ink
(Example)
Marking of the admissible
solvent (Example)
1 – Reservoir tank unit
4 – Reservoir tank „Solvent“
2 – Hinged cover lid
5 – Refill bottle „Solvent “
3 – Reservoir tank „Ink“
6 – Refill bottle seal
3
1
4
N.º 77001-00001
N.º 70000
-00001
2
5
6
