Leibinger JET3 up - Job Editor Settings

Group 8 Job Editor Page 291
JET3up Release R1.06
8.6 Job editor settings
The drop-down menu <View> provides several options for view settings and the
basic settings for the job editor. The following functions are available:
 Enlarge and reduce display size (Zoom in/out)
 Show grid
 Catch active
 Editor Settings
1. Editor settings
With the option <Editor Settings> you can set the editor size (width and height
of the display area) as well as the grid size.
Proceeding:
 Press the button <View> (1) and the option <Editor Settings> (2).
 The window <Editor Settings> (3) is faded in.
 With the Arrow keys (4)
you can increase or reduce the values of the editor
size and the grid size by one step.
alternatively
 Click in the appropriate display field (5) of the value w
hich you would like to
change. A Numeric keypad opens for input. Now enter the requested value.
 The button <OK> (6) closes the window
INFORMATION
 Hint: The editor height is specified and cannot be changed.
 You will find further information regarding the working with
Numeric keypads in the chapter 6.4.1 Numeric keypad
2. Snap to grid function
The function enables the easy and exact positioning of an element at the grid.
When snapping is enabled objects are always aligned with the grid.
