8.5 Job settings
The dialog box <Job settings> is grouped in 4 tabs. The 4 groups are:
Printstyle
This tabs provides all parameters regarding the look and the size of the printout
Print parameter
This tab provides all parameters regarding the positioning of the printout and the
evaluation of sensors.
Encoder parameter
This tab provides all parameters regarding the speed and direction of the printout
whereby the speed/direction measurement can be done with an external encoder, a
speed defined internally or by the evaluation of external sensors.
Date change parameter
This tab provides the option of defining a date offset.
Figure 134 Job settings dialog box – Available tabs
INFORMATION
You will find an overview and further information regarding the
available parameters in chapter 8.2.5 Job settings dialog box -
Overview
