Leibinger JET3 up - Counter Assignment; Figure 132 Settings for Counter Assignment

Group 8 Job Editor Page 253
JET3up Release R1.06
8.4.6 Counter assignment
With this function you can assign a counter to an object in order to create a
periodically repeated object.
Basically a counter can be assigned to all kinds of objects:
 Text objects
 Barcode objects
 Graphic objects
 Time/Date objects
 Counter objects
 Shift code objects
 External text objects
With an activated assigned counter you can define at which counter re
ading the
object shall be printed. With this function it is possible to create a print job with
periodically repeated elements. See example for details.
Please see details regarding the counter function in chapter
8.7.3.1 Counter parameter
Figure 132 Settings for counter assignment
Check box
Print, when counter
=end value
Settings for counter assignment
Non-printable counter in the preview of
the job editor
With this box checked a counter is
assigned to the object.
Arrow keys Counter ID
With these spin buttons you choose the
required counter. You’ll have to make
sure that there is a counter object
defined in the job and and that the
correct ID is set.
If there’s no counter defined in the
current print job or in case you set the
wrong ID the counter assignment
settings will be ignored.
Selected counter object
