GS1-ECC200 rectangle
 Same specifications as the GS-1 ECC200 square but:
 rectangular with sizes from 8×18 to 16×48 (even values only)
PPN-ECC200 square
 The PPN Code is the machine-
readable identification of retail packs with the
Pharmacy Product Number.
 The ECC200 data matrix code is used for the encoding of the information.
PPN-ECC200 rectangle
 Same specifications as the PPN ECC200 square but:
 rectangular with sizes from 8×18 to 16×48 (even values only)
QR-Code
 QR code (Quick Response Code) is the trademark of a type of matrix
barcode.
 The amount of data that can be stored in the QR code symbol depends on
the data type (mode, or character set), version (1, …, 40, indicating the
overall dimensions of the symbol), and error correction level.
IMPORTANT

The JET3up job editor offers the possibility to add the content of
each bar code type as plain text.
 Due to technical limits the maximum number of vertical dots is
32. For this the maximum size of data matrix codes is also
determined by this limit. Using a rectangle data matrix code may
be a work around.
8.7.1.2 Bar codes: Object creation and properties
Please see point 1 of Figure 161
In the job editor you can create an <Bar code> object either with the <Insert>
drop-down menu (1) or with the direct button (shortcut) for <Bar codes> (2).
Both will open the dialog box for the object settings (3).
