Leibinger JET3 up - Figure 21 Keyboard Design; Keyboard

Page 78 Job Editor Group 8
Release R1.06 JET3up
6.4.2 Keyboard
Figure 21 Keyboard design
Standard characters
Special characters expanded font
Caps Lock/Standard characters
Caps Lock/ Special characters - expanded font
1 –Button <Return>
3 – Button<Caps Lock>
2 –Button <Special characters>
2
1
3
3
