Leibinger JET3 up - Figure 184 - Job Editor: Carry out Replacements - Example 2

Page 364 Job Editor Group 8
Release R1.06 JET3up
Figure 184 Job editor: Carry out replacements – Example 2
1 – Menu item <Format>-<Object>
10 – Open keyboard
2 – Original counter object
11 – Change settings
3 – Direct button <Object settings>
12 – Confirm settings with <Enter>
4 – Tab <Replacements>
13 – Filled-in replacement fields
5 – Dialog box <Object settings>
14 – Use scroll buttons
6 – Drop down list <Type>
15 – Button <OK>
7 – List item <Figures>
16 – Button <Cancel>
8 – Setting fields <Replacement>
17 – Changed counter object
9 – Original element designations
3
4
5
6
7
1
2
1
2
3
7
10
4
8
9
11
5
6
12
15
16
13
14
17
8
