Page 84 Job Editor Group 8
Release R1.06 JET3up
Figure 24 Switch-on procedure with password protection
1 – TFT-Touch-Display
7 – Input field <Password>
2 – Message box <Initialization>
8 – Software keyboard
3 – Main Window
9 – <Enter> key
4 – Message box <Bleeding>
10 – <Login> Button
5 – <Cancel> Button
11 – Indicator for currently logged-in user
6 – Dialog box <Log-in>
1
2
6
5
3
4
7
8
9
10
7
11
