Leibinger JET3 up - Save Info File

Group 8 Job Editor Page 229
JET3up Release R1.06
The following system information are displayed:
 Several information about hard and software versions (1-8)
 Network information. The data correponds with the IP-settings in the
<Basic
settings> dialog box (10).
 Information about the drop off curve (11-12).
 The illustration of the drop break-off curve (12) is only availabl
e as long as the
printer is in <Print mode> (nozzle open)
! Otherwise a symbol with a red cross
is displayed.
With the button <Export> (11) you can save the system information on an
external memory device (e.g. USB-stick). The button <Close> (12)
closes the
dialog box.
7.6.1.1 Save info file
The displayed system information can exported to an external memory device like
an USB-stick or a network storage device.
Important
In order to store the data on a network storage device the network path
settings have to be configured. Please see chapter 7.3.1.7 Network ID
for details.
The socket for the USB stick is located on the reverse side of the printer.
Please see chapter 5.5 Interfaces for details.
Important
It does not matter whether the <Export> button is used on page 1 or
page 2 of the <Info> dialog box. The content of both information pages
will always be exported at once.
If there is an illustration of the drop break-o
ff curve available it will also
be exported as graphic file (*.jpg).
In addition the current data logging file will also be exported
automatically. Please see chapter 7.4.5 Data logging - Log file
for details
about the data logging file.
