Leibinger JET3 up - Figure 27 - Menu Layout 2

Page 88 Job Editor Group 8
Release R1.06 JET3up
Figure 27 Menu layout 2
10 – Tab caption
17 – Tab bar
11 – Enabled button
18 – Input /display field with arrow keys
12 – Disabled button
19 – Preview illustration
13 – Activated button
20 – Check boxes
14 – Title bar dialog box
21 – Radio buttons with preview
illustrations
15 – Tab
22 – Preview
16 – Dialog box
10
11
12
13
14
15
8
16
9
18
20
22
19
20
17
19
9
21
18
