Leibinger JET3 up - Extern Text: Fixed Length - Object Creation and Properties

Group 8 Job Editor Page 335
JET3up Release R1.06
8.7.5.1.2 Extern Text: fixed length – Object creation and properties
See figure 176
In the job editor you can create an <Extern Text> object either with the <Insert>
drop-down menu (1) or with the direct button (shortcut) for <Extern Text> (2).
This will open the dialog box for the object settings (3).
On the tab <Global settings> (4) you can enter the font settings (5)
, select font
options (6) or define the positioning of the object (7).
INFORMATION
For details about the global settings of an object please see chapter
8.4 Object settings
On the tab
<Extern Text>
you can choose the type of the extern text. The
following description refers to the option <Extern Text: fixed length> (9)
. The
<Extern Text: variable length> and the <Mailing>
options are described
separately.
The type <Extern Text: fixed length>offers several options:
 Settings for double prints (11)
 Settings for wildcards (10)
 Settings for an offset (12)
Setting for double prints
With the check box checked off (11) each received character string will only be
printed once. In case there is another PrintGo signal received before any new data
were received the printer will switch to <Print Stop>: the green <Print Start>
button switches off and the red <Print Stop> button switches on. Additionally a
message box is displayed:
You will have to confirm the error message and restart the print-out again by
pressing the green <Print Start> button.
