Page 52 Transport/Start up Group 5
Release R1.06 JET3up
Proceeding (Example: Filling of solvent)
WARNING
Risk of fire and injury! Absolutely observe!

Before filling the device with the consumables, measures for the
electrostatic discharge have to be made!
 Highly flammable! Burning gases and liquids
may cause severe
burns. Keep sources of ignition away from the printer!

Always statically discharge the printer and yourself before filling
the reservoirs! Simply touch the housing of the printer to discharge
the equipment and stand on a grounded surface
wearing ESD
shoes during filling!
 Protective equipment is necessary!
Read the safety data sheets
and the personal protective equipment rules and regulations!
ATTENTION
The sealing of the refill bottle must not be opened!

Open the lid
(2)
of the reservoir tank unit
(1)
.
 Open the screw cap of the solvent tank (4) and of the refill bottle (5).

Put the refill bottle on the solvent tank. The seal of the bottle will be breached
and the closing valve of the tank will open automati
cally and the reservoir tank
is filled up.
 Wait until the refill bottle is completely empty.

Take out the empty refill bottle. The closing valve of the reservoir tank will be
closed automatically.
 Finally close the reservoir tank and empty refill bottle
carefully with the srew
caps.
ATTENTION
The reservoir tanks as well as the empty refill bottles have to be
closed carefully after filling.
