2-124 Service Manual
7462
Sensor (ADF media exit) late jam service check
3
Check the sensor (ADF media exit) for proper connection.
Is the above component properly connected?
Replace the
sensor (ADF
media exit).
Go to “Sensor
(standard bin
exit) actuator
assembly
removal” on
page 4-86 or
“Sensor (ADF
media exit)
bracket
assembly
removal (X651)”
on page 4-87
Replace the
connection.
4
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the ADF
controller card
assembly.
Go to “ADF
controller card
removal” on
page 4-62.
Go to step 5.
Problem resolved.
5
Perform a print test using the ADF.
Does the problem remain?
Contact next
highest level of
tech support.
Problem resolved.
Use this procedure for the following jams:
• 294.01
Step Check Yes No
1 Check the original document condition.
Is the original document free of paper clips and staples as
well as damage such as creases, tears, holes or excessive
wear?
Go to step 2. Remove damaged
original document
and replace with a
new undamaged
original document.
Perform a ADF
test. If the problem
remains, go to
step 2.
2
Check the ADF rolls for wear.
Is the ADF feed/pick roll assembly or the ADF separation
roll guide assembly free of excess wear?
Go to step 3. Clean or replace
the ADF feed/pick
roll assembly or
the ADF
separation roll
assembly.
Go to “ADF feed /
pick roll
assembly
removal” on
page 4-56 or
“ADF separator
torque limiter
assembly
removal” on
page 4-58.
To Next Page
