Lexmark T65 Series Service Manual

Repair information 4-23
7462
Go Back
Previous
Next
Media out actuator removal
1. Remove the pick arm assembly. See “Pick arm assembly removal” on page 4-28.
2. Release the hook (A) securing the media out actuator to the unit.
3. Remove the media out actuator.
Media support removal
1. Gently detach the two bosses (A) of the media support from the machine.
2. Remove the media support.
A
A
A
