MFP stapler assembly handle cover removal
1. Remove the left and right cover. See “MFP stapler assembly left cover removal” on page 4-197 and
“MFP stapler assembly right cover removal” on page 4-196.
2. Remove the two screws (A) on each side of the.
3. Lift up and to the rear to remove the cover.
A
A

Lexmark T65 Series Specifications

General

Print Resolution	1200 x 1200 dpi
Print Technology	Laser
Standard Paper Capacity	650 sheets
Connectivity	USB, Ethernet
Operating Systems Supported	Windows, Linux
Maximum Paper Size	8.5 x 14 inches
