Diagnostic aids 3-59

7462

Go Back

Redrive motor assembly

The redrive motor assembly is a DC motor that drives the redrive assembly that transports the media into the

standard bin or output option.

Electrical components and controller

Switch (printer front door interlock)

Redrive motor

assembly

Main drive

motor assembly

Main cooling fan

System card

assembly

LVPS card

assembly

LVPS

cooling fan

Print cartridge

cooling fan

HVPS card

assembly
