Repair information 4-237

7462

Go Back

Offset stacker right cover removal

1. Remove the two screws (A) on the inside of the exit bin compartment securing the right cover.

2. Pull out on the front side of the right cover to disengage the tabs.

3. Remove the offset stacker right cover.
