Connector locations 5-1
7462
Go Back
Previous
Next
5. Connector locations
Locations
Sensors–ADF
Sensors–Flatbed
Switch (ADF
closed interlock)
Sensor (Media exit)
Sensor (ADF lower
door interlock)
Sensor (ADF document set)
Sensor (ADF front registration)
Sensor (ADF rear registrati
Sensor (ADF sheet through)
Sensor (ADF top
door interlock)
Sensor (ADF media length)
nsor (ADF media width)
ADF pick solenoid
