Repair information 4-155

7462

Go Back

High capacity input tray (HCIT) cover, rear removal

Note: Carefully remove the base machine from the HCIT tray assembly before proceeding.

1. Remove the four screws (A) securing the HCIT cover, rear to the drawer.
