Sensor (duplex input) removal
1. Remove the duplex input sensor assembly. See “Duplex input sensor assembly removal” on page 4-10.
2. Release the hooks (A) securing the senor (duplex media path) to the bracket.
3. Remove the sensor (duplex input).
Sensor (media low) removal
1. Remove the pick arm assembly. Go to “Pick arm assembly removal” on page 4-28.
2. Release the hooks (A) securing the sensor (media low) to the assembly.
3. Remove the sensor (media low).
Sensor (media empty) removal
1. Remove the pick arm assembly. See “Pick arm assembly removal” on page 4-28.
2. Release the hooks (A) securing the sensor (media empty) to the assembly.
3. Remove the sensor (media empty).
A
A
A
