Lexmark T65 Series Service Manual

Repair information 4-215
7462
Go Back
Previous
Next
MFP stapler assembly sensor (bin full receive) removal
1. Remove the right cover. See “MFP stapler assembly right cover removal” on page 4-196.
2. Remove the two screws (A) securing the sensor (bin full receive).
3. Disconnect the harness and remove.
MFP stapler assembly sensor (media in stapler) removal
1. Remove the stapler unit assembly from the . See “MFP stapler assembly stapler unit assembly
removal” on page 4-207.
2. Using a flat-blade screwdriver, release the tabs (A) securing the sensor.
A
A
