Lexmark T65 Series Service Manual

4-50 Service Manual
7462
Go Back
Previous
Next
Hard drive removal
1. Remove the side cover, left. See “Side cover, left removal (model X658)” on page 4-120.
2. Loosen the two screws (A) securing the hard drive to the rear of the machine.
3. Remove the system card metal plate.
4. Gently detatch the hard drive from the system card.
5. Disconnect the connector from the system card.
A
Hard drive connector
