Diagnostic information 2-147
7462
Sensor (output pass through) lingering jam service check
Sensor (output pass through) static jam service check
Step Check Yes No
1 Check the output option for proper installation.
Is the above component properly installed?
Go to step 2. Remove then
reinstall the output
option
2
Check for obstructions in the media path between the
Sensor (output pass through) machine and the media bin.
Is the media path free from obstructions?
Go to step 3. Remove
obstructions.
3
Check the sensor (output pass through) for proper
operation.
1. Enter the diagnostic mode
2. Select Output bin tests
3. Select Sensor test
4. Select Output bin x
5. Observe the line item “passthru”
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked.
Go to step 5. Go to step 4.
4
Check the above sensor for proper connection.
Is the above sensor connected properly?
Replace the
sensor (output
pass through).
Go to “4-bin
mailbox
assembly sensor
(pass through)
removal” on
page 4-231.
Replace the
connection.
5
Perform a print test using the output option.
Does the error continue?
Replace the output
option.
Problem resolved.
Ste
p
Check Yes No
1 Check the media path for partially fed or jammed media.
Is the media path free from partially fed or jammed media?
Go to step 2. Remove any pre-
staged or jammed
media.
2
Check the sensor (output pass through) for proper
operation.
1. Enter the diagnostic mode
2. Select Output bin tests
3. Select Sensor test
4. Select Output bin x
5. Observe the line item “passthru”
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked.
Go to step 4. Go to step 3.
