2-128 Service Manual
7462
Sensor (input) late jam service check.
Use this procedure for the following jams:
• 200.07 • 230.04 • 230.06 • 237.00 • 239.11
• 241.06 • 214.10 • 241.11 • 241.12 • 241.14
• 241.15 • 241.16 • 241.18 • 242.09 • 250.03
• 250.06 • 250.07 • 250.08 • 250.09 • 250.10
• 250.11 • 260.07 • 260.10 • 260.11 • 260.12
• 260.14 • 260.15 • 260.16
Step Check Yes No
1 Check the media size setup and tray guides for all media
trays.
Does the media size, in use, match the size set for all media
trays?
Go to step 2. Replace the
media, or change
the media size
setup.
2
Check the media trays for overfilling.
Are any of the media trays overfilled?
Remove any
excess new
media.
Go to step 3
3
Check the media condition in all media trays.
Is any of the media in any of the media trays crumpled or
damaged?
Replace the
damaged media
with new.
Go to step 4.
4
Check the media tray pass through areas for obstructions.
Are the pass through areas in all the media trays free from
obstructions?
Go to step 5. Remove
obstructions.
5
Check media origination.
Did the media originate from the MPF?
Go to step 6. Go to step 8.
6
Check the MPF pick roll assembly.
Is the above component free of excess wear and
contamination?
Go to step 7. Clean or replace
the MPF pick roll
assembly.
Go to Go to “MPF
pick roll
assembly
removal” on
page 4-26.
7
Perform a MPF print test and check the MPF pick solenoid
for proper operation.
Does the above component operate properly?
Go to step 17. Replace the MPF
pick solenoid.
Go to “MPF pick
solenoid
assembly
removal” on
page 4-26.
8
Check media origination.
Did the media originate from the internal duplex?
Go to step 9 Go to step 13
9
Check the internal duplex media path for obstructions.
Is the above component free from obstructions?
Go to step 10 Remove
obstructions.
To Next Page
