3-52 Service Manual

7462

Go Back

Transfer

Transfer roll assembly

The transfer roll assembly applies charge to the rear surface of the media when the media passes between the

transfer roll assembly and photo conductor (drum). Thus, the toner image is transferred from the photo

conductor (drum) surface to the media surface.

Transfer roll
