Repair information 4-251

7462

Go Back

Offset stacker sensor (bin full send) removal

1. Remove the stapler/stacker controller card assembly. See “Stapler/stacker controller card assembly

removal” on page 4-247.

2. Remove the two screws (A) securing the staple finisher sensor (bin full send).

3. Disconnect the harness and remove.
