2-126 Service Manual
7462
Sensor (ADF media exit) lingering jam service check
Use this procedure for the following jams:
• 294.03
Step Check Yes No
1 Check the original document condition.
Is the original document free of paper clips and staples as
well as damage such as creases, tears, holes or excessive
wear?
Go to step 2. Remove damaged
original document
and replace with a
new undamaged
original document.
Perform a ADF
test. If the problem
remains, go to
step 2.
2
Check the ADF rolls for wear.
Is the ADF feed/pick roll assembly or the ADF separation
roll guide assembly free of excess wear?
Go to step 3. Clean or replace
the ADF feed/pick
roll assembly or
the ADF
separation roll
assembly.
Go to “ADF feed /
pick roll
assembly
removal” on
page 4-56 or
“ADF separator
torque limiter
assembly
removal” on
page 4-58.
3
Check the media path for contaminates.
Is the media path free of excess media dust and foreign
objects such as paper clips and staples?
Go to step 4. Remove all
contaminates from
the media path.
4
Check the sensor (ADF media exit) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Observe the line “sensor (ADF media exit)”
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 6. Go to step 5.
5
Check the sensor (ADF media exit) for proper connection.
Is the above component properly connected?
Replace the
sensor (ADF
media exit).
Go to “Sensor
(standard bin
exit) actuator
assembly
removal” on
page 4-86 or
“Sensor (ADF
media exit)
bracket
assembly
removal (X651)”
on page 4-87
Replace the
connection.
To Next Page
